Name: Lagged Drum Pulley
Brand: JUXIN
SKU: 261911946

Introduction

A lagged conveyor pulley is a pulley on a belt conveyor system that has a layer of material applied to its surface. The lagging provides a number of benefits, including increased traction between the belt and the pulley, improved belt tracking, and protection against wear and corrosion.

The lagging material is typically made from rubber, but can also be made from other materials such as ceramic or polyurethane. The lagging is bonded to the surface of the drum using a specialized adhesive, and is typically applied in strips or segments to allow for easy replacement if necessary.

The lagging can be smooth or grooved, depending on the specific application and the type of belt being used. Smooth lagging provides increased traction and reduces slippage, while grooved lagging is designed to improve belt tracking and reduce the risk of belt damage.

lagged drum pulley

Application

The lagged material services several purposes, primarily related to improving the friction and grip between the pulley and the conveyor belt. It is an important component that helps prevent belt slippage, enhances overall system efficiency, and protects the pulley from wear.

The Rubber Lagging Pulley can be head pulley, tail pulley, take-up pulley, snub pulley, and bend pulley. Plain Rubber Lagged Pulley can be used in various industries, including mining, aggregate, port, power, steel, bulk material handling, and more.

Design

Wing Pulley / lagged drum pulley

A lagged drum pulley is a type of conveyor belt pulley that has a layer of rubber or ceramic lagging material on its surface. The purpose of the lagging is to improve the grip between the conveyor belt and the pulley, which helps to reduce slippage and improve the overall efficiency of the conveyor system.
The design of a lagged drum pulley typically involves selecting the appropriate lagging material based on factors such as the type of conveyor belt being used, the operating conditions of the conveyor system, and the specific requirements of the application. The lagging material is then bonded to the surface of the pulley using a specialized adhesive.
In addition to the lagging material, the design of a lagged drum pulley also includes features such as the diameter and width of the pulley, the type of bearings used to support the pulley, and the method of attachment to the conveyor system.

Advantage

Rubber Lagging Pulley Structure

Diamond Rubber Lagged Pulley

Diamond Profile Rubber lagged pulleys. Diamond grooved lagging features a pattern of diamond-shaped grooves on the lagging surface. This design improves traction and helps to channel water and debris away from the pulley, preventing slippage.

Ceramics Rubber Lagged Pulley

Ceramics & Profile Rubber lagged pulleys. Ceramic lagging incorporates ceramic tiles embedded in a rubber matrix. This combination enhances wear resistance and provides additional grip, making it suitable for applications involving abrasive materials.

Herringbone Lagged Pulleys

Herringbone Profile Rubber lagged pulleys. Herringbone lagging has a pattern of diagonal grooves resembling a herringbone. This design helps to improve the grip between the pulley and the belt.

Plain Rubber Lagged Pulley

Plain and Smooth Rubber lagged pulleys. Plain Rubber Lagging for non-drive pulleys to provide better traction for the conveyor belt. Plain rubber lagging is a common and versatile choice for conveyor drum pulleys.

Production

Intelligent Production Workshop

Hebei, May 1st , 2023, JUXIN is thrilled to announce the triumphant completion and utilization of its state-of-the-art 6,000 square meter intelligent production workshop.

Intelligent Idler Production Line

Hebei, June 1st, 2023,JUXIN announces the successful implementation of its state-of-the-art Intelligent Idler Production Line.

Certificate

Hot Tags: lagged drum pulley, China lagged drum pulley manufacturers, suppliers, factory, lagged pulley, a fixed pulley, line pulley, differential pulley, Herringbone Lagged Pulleys, rope pulleys for sale


BW	D	[T] KN·m	[δ] KN	A	L	L2	K	Q	P	N
500	250	0.63	15	850	600	495	110	260	320	90
	315	1.0	20			495	110	280	340	100
	400	1.25	20			495	110	260	320	90
	500	1.6	30			495	110	280	340	100
650	315	1.25	25	1000	750	570	110	260	320	90
	400	2.0	35			570	110	280	340	100
	500	3.5	40			570	140	350	410	120
	630	4.1	40			570	140	350	410	120
800	315	1.25	25	1300	950	720	110	260	320	90
	400	2.0	30			720	110	280	340	100
	500	2.5	30			720	140	350	410	120
	630	6	50			740	170	380	460	135
	800	7	50			740	170	380	460	135
	1000	12	80	1300		740	210	440	530	155
	1250	40	270	1400		870	350	640	780	240
1000	400	2.5	30	1500	1150	820	140	350	410	120
	500	6.3	75			840	170	380	410	120
	630	6	40			840	170	380	460	135
	800	12	73			840	210	440	530	155
	1000	12	80			840	210	440	530	155
1200	500	6.3	60	1750	1400	965	170	380	460	135
	630	12	52			975	210	440	530	155
	800	20	110			975	250	480	570	170
	1000	27	160	1850		1025	250	520	640	200
	1250	52	320	1900		1150	350	750	900	290
1400	800	20	100	2050	1800	1125	250	480	570	170
	1000	27	160	2050		1125	250	520	640	200
	1250	52	260	2100		1250	350	750	900	290
1600	800	20	120	2250		1235	250	520	640	200
	1000	27	160	2250		1245	300	570	700	220
	1250	66	450	2350		1375	350	750	900	290
	1400	80	520	2350		1385	410	840	1000	310
1800	800	20	160	2450	2000	1335	250	520	640	200
	1000	40	320	2500		1430	350	640	780	240
	1250	66	450	2550		1485	410	750	900	290
	1400	80	450	2550		1485	410	840	1000	310
